6G32P- EF86 6267 6CF8 6BK8 Z729 6F22 CV2901 and 50 similar items

6J32P High frequency pentode. Designed for use in the first stages of recording and sound-reproducing equipment. Durability not less than 3000 hours. Weighs less than 15 g. Key specifications for 6?32?: The filament voltage ...... 6,3 0,6 In The filament current of 0.2 0.015 A The anode voltage nominal (constant) ...... 250 In The anode voltage limit (constant) ...... 300 In The anode current ...... 3 1 mA The cathode current limiting ...... 6 mA The first grid voltage nominal (constant) ...... -2 In The grid voltage of the first lowest ...... Of 1.4 In The second grid voltage nominal (constant) ...... 140 In The second grid voltage limit (constant) ...... 200 Current of second grid ...... no more than 1 mA The power dissipated by the anode limit ...... 1 W The power dissipated by the second grid, the limit ...... 0.2 W The voltage between cathode and heater limit (DC): - at a negative potential heater ...... 100 In - at a positive potential heater ...... 50 In The steepness of the characteristics ...... 1,8 0,5 mA/V Internal resistance ...... 2.5 megohms The resistor in the grid of the first limit ...... 3 IOM Capacity input ...... about 4 pF Capacity output ...... about 5.5 pF Capacity checkpoint ...... not more than 0.05 pF Making ...... glass miniature. Lot 2pcs 100% Original NEW! Note about Feedback: Please leave me feedback when you receive your item and are happy with the transaction. If you have any questions or concerns, PLEASE contact me first before leaving negative feedback. I always strive to resolve any problems and make our customers happy. Note About Delivery Time: I try to send your item as soon as possible, Normally no later than 3 days after payment is received. arrive time is contingent on the carrier.
