Rosemount 300S1AAK5 Pressure Transmitter and 17 similar items

Rosemount 300S1AAK5 Pressure Transmitter 3051S1CD1A2A11A1AK5 Pre owned/ normal wear/ Untested/ We were told this was pulled from working environment but cannot test any further so we are selling as is/ Rosemount 300S1AAK5 is a housing/assembly code for a Rosemount 3051S pressure transmitter, rather than a standalone transmitter model. From the available product and manual references, here is what can reliably be said about a Rosemount 3051S built with a 300S1AAK5 housing: It is part of the Rosemount 3051S ?SuperModule? pressure transmitter family (used for differential, gage, or absolute pressure depending on the full 3051S model code). The 300S housing kit is specifically designed as the field housing for 3051S transmitters, providing the enclosure, terminal compartment, and covers. Typical 3051S transmitters with 300S housings are 2?wire, 4?20 mA with HART digital signal, powered from roughly 10.5?42 VDC depending on exact option code. Pressure ranges for 3051S units span from a few inches of H?O up to 10?000 psi depending on the sensor range code (1A?5A etc.); the 300S1AAK5 code alone does not define that range, you must read the full 3051S model tag (for example 3051S1CD3A2E11A1AB4K5?300S1AAK5). The housing and transmitter are certified for use in hazardous locations when properly installed and with covers fully engaged, per the 3051S safety and installation manual.? What you likely still need For sizing, calibration, or replacement, you will need the full model string from the nameplate (for example, ?3051S1CD3A2E11A1AB4K5 / 300S1AAK5?) rather than just 300S1AAK5. That full code tells you: measurement type (DP/gage/absolute), range, materials, electronic output, and process connection. SHELF:83 SA
