Brand New PNL1600 PowerLift® Magnets Rare and similar items

PNL1600PowerLift Magnets These compact yet powerful rare earth PowerLift lift magnets can be used on flat or round surfaces and contain an internal release on/off device that does not contact or damage the surface of the part being lifted. Permanent magnetic lifts eliminate the fear of dropping the load being lifted due to power failures. On/Off, Permanent Rare Earth Lifting Magnets These compact, yet powerful, rare earth lift magnets are designed for lifting thick, non-flexing steel. They can be used on flat or round surfaces and contain an internal release on/off device that does not contact or damage the surface of the part being lifted. Permanent magnetic lifts also eliminate the fear of dropping the load being lifted due to power failures. Benefits On/off rare earth design Lifts flat or round loads Easy internal manual release does not contact the load Heat resistant up to 180F (82C) ASME B30.20 BTH-1 Design Category B Service Class 3 Specifications: PNL1600 Compare with other models Measurements in inches and lbs Height 8.75 Length 10.75 Weight 51 Bail Height 3.5 Bail Thickness 0.625 Bail Width 2.25 WLL- Working Load Limit 1600 Handle Length 9 Magnet Height 4.75 Magnet Length 9.125 Magnet Width 4.875 Magnetic Pole Quantity 2 Flat Plate Working Load Limit (WLL) in lbs (kg) *Max Sheet Length Due To Sag For Material Thickness For Single Magnet Use Flat Plate Working Load Limit (WLL) in lbs (kg) *Max Sheet Length Due To Sag For Material Thickness For Single Magnet Use SKU 1/4" PLATE (6' Ln) 3/8" PLATE (8' Ln) 1/2" PLATE (8' Ln) 3/4" PLATE (8' Ln) 1" PLATE (10' Ln) 2" PLATE (10' Ln) 3" PLATE (10' Ln) PNL1600 NA CF 800 (362) 1600 (726) 1600 (726) 1600 (726) 1600 (726) NOTE: Working Load Limit (WLL) lifting values for the PowerLift Magnets are stated at 33% of the actual value. We recommend when lifting sheets over 8?, use 2 or more lifts on a spreader bar to prevent sheet flexing, sagging or peel-off. Thin material is susceptible to magnetic bleed through, resulting in two sheets being lifted at once. Round Item Lifting Values are based on ideal conditions. Pipe length, wall thickness, diameter and surface condition can all affect the magnet?s performance. Please consult the factory before specifying these magnets for use on round materials. *These maximum sheet lengths are selected due to the sag characteristics of the specified sheet. The item to be lifted must cover the entire length and width of the magnetic poles to properly engage and release the part. CF = Consult Factory NA = Not Applicable (Magnets listed will not turn ?ON? on specified material thicknesses.) Round Lifting Working Load Limit (WLL) in lbs (kg) Round Lifting Working Load Limit (WLL) in lbs (kg) SKU Working Load Limit lbs(kg) Minimum Diameter (in) Minimum Thickness (in) PNL1600 800 (362) 4 1 NOTE: Working Load Limit (WLL) lifting values for the PowerLift Magnets are stated at 33% of the actual value. Round Item Lifting Values are based on ideal conditions. Pipe length, wall thickness, diameter and surface condition can all affect the magnet?s performance. Please consult the factory before specifying these magnets for use on round materials. *These maximum sheet lengths are selected due to the sag characteristics of the specified sheet. The item to be lifted must cover the entire length and width of the magnetic poles to properly engage and release the part. CF = Consult Factory NA = Not Applicable (Magnets listed will not turn ?ON? on specified material thicknesses.)
