ProMill 8000 CNC Machining Center (INTELITEK) USED Good condition. Pulled out from working source. CNC Milling Technology introduces students to the fundamentals of CNC (Computer Numerical Control) milling by working with a variety of machining applications with the ProMill 8000. Students learn the fundamentals of CNC milling by working with industrial-based equipment to accurately machine series of complex parts. Students observe and experience CNC’s superiority over time-consuming, less accurate, manually controlled machine tools. Activities challenge students to develop and edit programs, and machine assorted parts. Students gain hands-on experience in proper machine set up, cutting tools selection, tool path simulation and machining center operation. Students design solutions for industrial CNC milling applications with an emphasis on real industrial concerns, such as optimized programming, accurate milling and increased productivity. The machining center features an intuitive software interface and conforms to industrial EIA, ISO, Fanuc and G M code standards. Specifications Axis Travel X Axis, max: 280 mm / 11? Y Axis, max: 152 mm / 6? Z Axis: 270 mm / 10.625? Work Area Table Size: 550160 mm 21.6”x6.3? No. of T-Slots: 3 T-slot size: 12 mm 0.47? Max. table load: 35 Kg / 77 lbs Spindle Motor Type: Brushless Motor power: 1.34 hp, 1000 w Spindle speed: 100 – 5000 RPM Spindle taper: ISO20 Max. tool diam.: 10 mm / 0.375? Throat: 232 mm / 9.130? Accuracy Position accuracy: 0.038 mm / 0.0015? Repeatability: 0.010 mm / 0.0004? Dimensions Machine size Width: 1280 mm / 50.40? Depth: 895 mm / 35.23? Height: 1845 mm / 72.64? Shipping size Width: 1420 mm / 55.91? Depth: 1060 mm / 41.73? Height: 2035 mm / 80.12? Axis Drive Motors Axis motor type: AC servo X axis: 400w Y axis: 400w Z axis: 750w Rapid feed rate: 5000 mm/min 197 ipm Feed rate: 2540 mm/min 100 ipm Air Supply Requirements 620 kPa (90 psi) Power Requirements United States 115 VAC (+5%/-10%) 60 Hz, 20A
