Danfoss compressor MLZ038T4LC9 and similar items

Application: medium and low-temperature refrigeration installations Description: Scroll compressors can be used with many refrigerants, allowing you to optimize the use of capital and storage space. Suitable for applications related to the transport of refrigerated goods. The optional noise shield dampens noise. Specification: gross weight: 43.33 Kg net weight: 39.33 Kg EAN: 5702428250030 refrigerants: R134a, R22, R404A, R407A, R407C, R407F, R507 high side max pressure: 31.1 bar viscosity: 32 cP number of starts per hour: 12 low side max pressure: 26.2 bar MCC: 15 A sight glass mounting: screwed filling with [Max]: 5.44 kg oil filling: 1.57 L low value of rated voltage at 50 Hz: 380 V low rated voltage at 60 Hz: 460 V low value of the voltage range at 50 Hz: 340 V low voltage range at 60 Hz: 414 V nominal cooling capacity, 50 Hz: 8.5 kW nominal cooling capacity, 60 Hz: 10.7 kW reference oil: 160HV displacement: 80.95 cm 3 rotor start-up current: 70 A rotational speed at 50 Hz: 2,900 rpm rotational speed at 60 Hz: 3500 rpm winding resistance 1-2: 2.32 Ohm winding resistance 1-3: 2.33 Ohm winding resistance 2-3: 2.36 Ohm RLA: 9.6 A suction port size: 0.875 inches size of the discharge connection: 0.5 inch suction pipe size: 0.875 in size of the discharge pipe: 0.5 inch oil drain: 1/4 "screw IP protection degree: IP22 connection type: soldered high value of rated voltage at 50 Hz: 400 V high value of rated voltage at 60 Hz: 460 V high value of the voltage range at 50 Hz: 460 V high voltage range at 60 Hz: 506 V overall height: 455 mm height of suction connection: 280 mm delivery hose height: 422 mm motor protection: internal compressor supply: 400V/~3/50Hz 460V/~3/60Hz safety valve: 32 bar standard connector: ODF diameter: 184 mm Additional information: Instructions provided: Installation instructions Delivered mounting: Assembly kit containing rubber silencers with sleeves Oil delivered: Filling with oil At our auctions, there is also a wide selection of HVACR devices, such as compressors, charging stations, solenoid valves, automation equipment, expansion valves, tools etc. from companies such as Danfoss, Mastercool, OLAB, CEME, Imperial, Appion, Fluid-o-Tech, Fieldpiece, RectorSeal, Honeywell, which we are authorized distributor. If you have any questions please feel free to contact us: We will be more than happy to help you in selection of suitable device. Gallery WIGMORS ul. Irysowa 5 51-117 Wroc?aw Poland tel. +48 71 326 50 11 fax +48 71 326 50 01 NIP: 915-000-01-99 WARRANTY All our products are new and have 12-months warranty, unless otherwise stated. Commercial Invoices are issued to all sales. PAYMENTS - PayPal SHIPPING Will ship within one business day from payment. Order will be shipped by courier service. Delivery time varies from 3 -15 business days and depends on country of destination. Worldwide shipment will be calculated individually. Shipment of multiple purchase can be combined into one favourable shipping rate. Dimensions and weight of the combined package can?t exceed standard values. Buyer is responsible for any import tax or other import duties.
